Product Details
Place of Origin: Jiangsu,China
Brand Name: Shenhong
Certification: ISO
Model Number: QHS
Payment & Shipping Terms
Minimum Order Quantity: 5 piece
Price: US $20-200 / Piece
Packaging Details: Export case
Delivery Time: 15 work days after deposit
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 Piece/Pieces per Month
Type: |
Two Ways Dual Sheave Hoisting Tackle |
Material: |
Iron |
Application: |
Hoisting,Pulling,Lifting |
Weight: |
6.3~18kg |
Rated Load: |
30~100KN |
Diameter(mm): |
Less Than 3 |
Type: |
Two Ways Dual Sheave Hoisting Tackle |
Material: |
Iron |
Application: |
Hoisting,Pulling,Lifting |
Weight: |
6.3~18kg |
Rated Load: |
30~100KN |
Diameter(mm): |
Less Than 3 |
Two ways dual sheave hoisting tackle
Feature:The block has opening in both sides,so it is convenient to assemble and disassemble the wire cable.
Notes:You must explain clearly which style is you needed in writing contract,hook style(G) or round eye style(H).
| Model | Rated load(KN) | Diameter of rope(mm) | Weight(kg) | Hook | Ring |
| QHS2-3 | 30 | ≤Φ9.3 | 6.3 | G | H |
| QHS2-5 | 50 | ≤Φ11 | 11 | G | H |
| QHS2-8 | 80 | ≤Φ13 | 16 | G | H |
| QHS2-10 | 100 | ≤Φ13 | 18 | G | H |
