5Km / H Hydraulic Puller Tensioner 110KV Conductor Stringing Equipment
110KV transmission line stringing equipments are used for overhead 110KV transmission line single or bundled cnductors stringing operation. We normally used 6 ton hydraulic puller with 4 ton hydraulic tensioner for single 500-630 mm2 conductor, or two of 3 ton hydraulic tensioner for 2 bundled conductors in 110KV transmission line.
1. SA-YQ60 Hydraulic Puller
| Item No. | 07031 |
| Model | SA-YQ60 |
| Max. Pulling Force (KN) | 60 |
| Continuous Pulling Force (KN) | 50 |
| Max. Pulling Speed (m/min) | 5km/h |
| Pulling force at max. speed: | 25 KN |
| Root Diameter of Bull wheel (mm) | Φ460 |
| Number of grooves | 7 |
| Max. Steel rope Diameter (mm) | Φ18 |
| Model of Diesel Engine | Water cooled diesel engine |
| Power of Diesel Engine | 77 KW |
| Rotate Speed of Engine (rpm) | 2800 |
| Electrical System | DC24V |
| Weight (kg) | 3000 |
| Dimension (m) | 3.80 x 2.10 x 2.30 |
Application:
The hydraulic puller is used to pull pilot steel wire rope for conductors stringing. It is fully hydraulic controlled, easily used and maintained
Features:
-Closed hydraulic circuit,infinitely variable speed control in both rotating directions.
-The max pulling force for stringing operation can be preset, pulling force in the rope can be read on the line pull gauge.
-Automatic over pulling protection system
-Spring applied hydraulic released brake acts automatically in case of hydraulic failure to ensure safety.
-Hydraulic oil cooling system.
-Heat treated wear-proof bull wheels
-With rigid axle for towing at high speed, the machine looks beautiful.
-Integral self-loading reel winder with automatic level wind.
-Mounted on trailer with rigid axle for towing at max. speed of 15 km/h on work site.
Main Components:
-Engine: Cummins water-cooled diesel engine.
-Main variable displacement hydraulic pump and main motor: Rexroth (German)
-Reducer: R.R. (Italian)
-Reel winder motor: Danfoss (Danish)
-Main hydraulic valves: Rexroth (German)
-Hydraulic instruments: (German)
-Radiator: AKG (German)
2. Hydraulic Tensioners (Suitable for both conductor and OPGW, ADSS optic fiber cable)
| Item No. | 07171 |
| Model | SA-YZ40A |
| Max. Tension Force (KN) | 40 |
| Continuous Tension Force (KN) | 35 |
| Max. Stringing Speed(km/h) | 5 |
| Max. Pullback force (KN) | 40 |
| Max. Pullback speed (km/h) | 2 |
| Diameter of wheel (mm) | Φ1200 |
| Number of grooves | 5 |
| Max. Cable Diameter (mm) | Φ32 |
| Model of Engine | Water cooled Cummins |
| Power of Engine | 37 KW |
| Rotate Speed of Engine (rpm) | 2800 |
| Electrical system: | DC24V |
| Weight (kg) | 2800 |
| Dimension (m) | 3.40 x 1.80 x 2.40 |
Application:
It is suitable for single conductor, earth wire,OPGW and ADSS optic fiber cable stringing in line stringing operation.
Features:
-Closed hydraulic circuit, infinitely variable tension force contril
-The max. tension/pull back force can be preset, the tension force can be read from tension gauge
-Spring applied hydraulic released brake acts automatically in case of hydraulic failure to ensure line safety
-Hydraulic oil cooling system
-Bull wheels lined with wear proof MC nylon lining segments
-With rigid axle for towing at max. speed of 15 km/h
Main components:
-Engine: Cummins water-cooled diesel engine
-Main pump and motor: Rexroth
-Reducer: R. R. (Italian)
-Hydraulic valve: Rexroth
-Hydraulic Instrument: (German)
-Radiator: AKG (German)
or Hydraulic Tensioner SA-YZ30A (Suitable for both conductor and OPGW, ADSS optic fiber cable)
| Item No. | 07155 |
| Model | SA-YZ30A |
| Max. Tension Force (KN) | 30 |
| Continuous Tension Force (KN) | 25 |
| Max. Stringing Speed(km/h) | 5 |
| Max. Pullback force (KN) | 20 |
| Max. Pullback speed (km/h) | 0.9 |
| Diameter of wheel (mm) | Φ1200 |
| Number of grooves | 5 |
| Max. Conductor Diameter (mm) | Φ32 |
| Model of Engine | S195GM |
| Power of Engine | 11KW |
| Rotate Speed of Engine (rpm) | 2200 |
| Electrical system: | DC12V |
| Weight (kg) | 1700 |
| Dimension (m) | 3.56 x 1.60 x 2.22 |
Application:
It is suitable for single conductor, earth wire,OPGW and ADSS optic fiber cable stringing in line stringing operation.
Features:
-Closed hydraulic circuit, infinitely variable tension force contril
-The max. tension/pull back force can be preset, the tension force can be read from tension gauge
-Spring applied hydraulic released brake acts automatically in case of hydraulic failure to ensure line safety
-Hydraulic oil cooling system
-Bull wheels lined with wear proof MC nylon lining segments
-With rigid axle for towing at max. speed of 15 km/h
Main components:
-Engine: Chinese famous branded water-cooled diesel engine
-Main pump: Sauer (USA)
-Reducer: Dinamic Oil (Italian)
-Hydraulic Instrument: (German)
-Radiator: AKG (German)
